Bloom Filter – Your Memory Friendly Liar

Figure: Created with GPT.

Introduction

Imagine a data structure that can confidently tell you “No, this item has never been seen before”, but might lie with a “Yes” even if the item isn’t really there. Welcome to the world of Bloom Filters, a probabilistic data structure that trades a bit of truth for a lot of speed and memory efficiency.

A Bloom Filter is designed to answer set membership queries like “Is this item in the set?” without storing the actual items. Instead, it stores hash values. It guarantees no false negatives, meaning if it says an item is not present, it definitely isn’t. But it may give false positives, i.e., say an item is present when it actually isn’t.

This makes it perfect for situations where space is tight and speed is essential like web caches, databases, or distributed systems.

How It Works

At the core, a Bloom Filter consists of:

• A bit array of size m, initialized to all 0s
• k independent hash functions that uniformly distribute inputs

Let’s say we want to insert the string "Home":

1. Hash "Home" with each of the k=3 hash functions.
2. Suppose the hash outputs are indices: 4, 5, 6.
3. We set the bits at these positions in the bit array to 1.

Next, we insert "Cake" and its hash indices are 1, 3, 4. We set those bits to 1 too.

Now, when we check for membership of "Home" again:

• We hash it using the same 3 hash functions → 4, 5, 6
• We check if all these bits are 1
  • If yes → “maybe present”
  • If any one is 0 → definitely not present

Why No False Negatives?

If a string was truly inserted, then all of its hash indices would have been set to 1. So if even one of those bits is 0, we can be certain it was never added. Hence, no false negatives.

Why False Positives?

Because different strings may produce overlapping hash indices. For example, "Cake" and "Home" both set index 4. A new query might coincidentally find all required bits set to 1 (by other elements), even if it was never added. Thus, false positives occur.

Can We Delete Items?

Here’s the problem: If we try to remove "Home" by resetting its bits (4, 5, 6) back to 0, we might accidentally unset a bit shared with another item (like index 4, which "Cake" also uses). This leads to false negatives for the "Cake", which violates the guarantee.

But in standard Bloom Filters, deletion isn’t supported. If false positives become too frequent (as the bit array fills up), the filter is typically reset and rebuilt.

Analysis

Let’s analyze the error probability:

Let:

• m = size of the bit array
• k = number of hash functions
• n = number of inserted elements

The probability that a particular bit set to 1 by a hash function:

\[P(\text{bit = 1}) = \left(\frac{1}{m}\right)\]

And the probability that the bit remain 0 by k hash function will be:

\[P(\text{bit = 0}) = \left(1-\frac{1}{m}\right)^{k}\]

The probability that a particular bit remains 0 after n insertions:

\[P(\text{bit = 0}) = \left(1 - \frac{1}{m}\right)^{kn}\]

So, probability a bit is 1:

\[P(\text{bit = 1}) = 1 - \left(1 - \frac{1}{m} \right)^{kn}\]

And for the Bloom filter to say it is positive all the bit from k function should be 1. Thus, the false positive probability (FPP) becomes:

\[FPP = \left(1 - \left(1 - \frac{1}{m}\right)^{kn}\right)^k\]

Optimal k and m

If you want a false positive probability p, and you plan to store n items:

• Optimal size of bit array: \(m = -\frac{n \ln p}{(\ln 2)^2}\)

• Optimal number of hash functions: \(k = \frac{m}{n} \ln 2\)

Choice of Hashing Functions

Hash functions for Bloom Filters should be:

• Independent, or at least statistically uncorrelated
• Uniform, i.e., they distribute values evenly
• Efficient, to minimize insert/query time

In practice, people use variations like MurmurHash, xxHash, or multiple seeds of MD5/SHA256 truncated to array size.

Applications

Bloom Filters are widely used in:

• Web Caches (e.g., checking if a URL is already cached)
• Databases (e.g., Cassandra, HBase use them to reduce disk lookups)
• Email Spam Filters (checking if an email has been seen)
• Networking (routing, duplicate suppression)
• Distributed Systems (e.g., tracking resource usage or membership)
